BIENVENIDO A
Solux
Solar Power Systems
Consultoría / Diseño / Instalación / Servicio
Tenemos el producto para tu necesidad
INVERSORES HIBRIDOS PARA SISTEMAS RESIDENCIALES Y COMERCIALES
Aplicaciones Residenciales y Comerciales
SOL-ARK 5K-2P
-
Max Allowed PV Power 3,250W + 3,250W = 6,500W
-
Max PV Power Delivered to Battery & AC Outputs 5,000W
-
2 MPPTs Output: 125-425V
-
Rated AC Output Current (A) 20.8 A
-
Continuous AC Power with Grid or Generator - 15,120W 63A L-L (240V) / 7,560W 63A L-N (120V)
-
Max continuous AC passthrough (A) 50A
-
Design (DC to AC) Transformerless DC
-
Battery Type - Lead-Acid or Li-Ion
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 40V-63V
-
Continuous Battery Charging Output - 120A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
5 years warranty
-
Max Allowed PV Power - 5,500W + 5,500W = 11,000W
-
Max PV Power Delivered to Battery & AC Outputs - 8,000W
-
2 MPPTs Output: 125-425V
-
Rated AC Output Current (A) 33.3 A
-
Continuous AC Power with Grid or Generator - 16,000VA L-L (240V) / 25,000VA L-L(240V)
-
Max continuous AC passthrough (A) 63A
-
Design (DC to AC) Transformerless DC
-
Battery Type - Lead-Acid or Li-Ion
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 40V-63V
-
Continuous Battery Charging Output - 185A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
Standard 5 years warranty (10 yr ext.*) (Contact Sales@sol-ark.com for 10 year extension)
SOL-ARK 8K-2PN
SOL-ARK 12K-2PN
-
Max Allowed PV Power - 6,500W + 6,500W = 13,000W
-
Max PV Power Delivered to Battery & AC Outputs - 12,000W
-
2 MPPTs Output: 125-425V
-
Rated AC Output Current (A) 37.5 A
-
Continuous AC Power with Grid or Generator - 15,120W 63A L-L (240V) 7,560W 63A L-N (120V)
-
Max continuous AC passthrough (A) 63A
-
Design (DC to AC) Transformerless DC
-
Battery Type - Lead-Acid or Li-Ion
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 40V-63V
-
Parallel Stacking Yes
-
Continuous Battery Charging Output - 185A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
3 phase applications, up to 3 inverters per line
-
Standard 10 years warranty
-
Max Allowed PV Power - 19,500w
-
Max PV Power Delivered to Battery & AC Outputs - 15,000W
-
3 MPPTs Output: 125-425V
-
Rated AC Output Current (A) 50 A
-
Continuous AC Power with Grid or Generator - 48,000W 200A L-L (240V) 24,000W 200A L-N (120V)
-
Max continuous AC passthrough (A) 63A
-
Design (DC to AC) Transformerless DC
-
Battery Type - Lead-Acid or Li-Ion
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 40V-63V
-
Continuous Battery Charging Output - 185A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
3 phase applications, up to 3 inverters per line
-
Standard 10 years warranty
SOL-ARK 15K-2PN
-
Max Allowed PV Power - 39,000W
-
Max PV Power Delivered to Battery & AC Outputs - 30,000W
-
4 MPPTs Output: 170-500V
-
Rated AC Output Current (A) 50 A
-
Continuous AC Power with Grid or Generator - 48,000W 200A L-L (240V) 24,000W 200A L-N (120V)
-
Continuous AC power from PV and from batteries (A) 83.4A (208V)
-
Design (DC to AC) Transformerless DC
-
Battery Type - Lead-Acid or Li-Ion
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 150V-500V
-
Continuous Battery Charging Output - 100A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
Standard 10 years warranty
-
Max Allowed PV Power - 78,000W
-
Max PV Power Delivered to Battery & AC Outputs - 60,000W
-
4 MPPTs Output: 200-850V
-
Rated AC Output Current (A) 50 A
-
Continuous AC Power with Grid or Generator - 102,000W | 160A L-N (277V)
-
Continuous AC power from PV and from batteries (A) 72.2A (208V)
-
Design (DC to AC) Transformerless DC
-
Battery Type - Li-Ion - 2 Inputs
-
Nominal DC Input 48V
-
Capacity 50 — 9900Ah
-
Voltage Range 160-800V
-
Continuous Battery Charging Output - 100A
-
Enclosure - Outdoor rated IP65 / NEMA 3R
-
Standard 10 years warranty
Los Inversores SolArk trabajan con la mayoría de las baterías Litio 48V
